Square Shape Vertical Roll up Fly screens

Available Models

  • MODEL V50-SQR is a roll-up fly mesh for vertical use only. The unit can be manufactured to your measurements with a maximum Width of 1400 mm and a maximum Height of 2000 mm

Technical Specifications

    The unit is designed for: EASY TO INSTALL, EASY TO USE AND EASY TO MAINTAIN.
    The shrink wrap pack includes complete material needed for installation. Each pack is clearly marked with identification and measurement specifications. The standard unit can be easily shortened as required. No screws or installation part are visible. Fly mesh is stored and protected in the head box if not in use
    All material used in the manufacturing process are in accordance to their relevant standards.
    Aluminum: ALLOY AA6063 in accordance to BS: 1474; DIN: 17615 Part-2
    Powder Coating: UV resistance RAL color, in accordance to BS: 6496: ISO: 2360
    Fiber Glass Mesh PVC coated: Fire retardant, in accordance to ASTM D 5035
    Plastic Parts: Nylon 06 in accordance to ASTM D1044 (Color Black or White)
    Rolli products are available in all RAL colors in addition wide range of wood color with grains. Design are also available match your frame and wall environment
    Measurement should be given as indicated overleaf. Include model TYPE, your identification numbers and the details of accessories (Handles and Colors)
    In each pack complete installation instructions are included which should be followed. However, fixing can vary on a case to case basis. (Frame to frame)
